LP+ / LPB+ Generation 3 planetary gearboxes

  • LP+ Generation 3 planetary gearbox with output shaft

  • LPB+ Generation 3 planetary gearbox with output flange

  • LPB+ Generation 3 planetary gearbox with belt pulley

  • Economy System with planetary gearbox LP+ Generation 3, pinion and Value Class rack

  • Motor mounting LPB+ planetary gearbox

Economical multitalent

Low backlash planetary gearboxes with output shaft or output flange. The LP+/LPB+ Generation 3 gearbox series combines maximum quality with economical precision.The LPB+ Generation 3 is especially suitable for compact belt drives.

Personal consultation

Do you have questions on products, or would you like to have a personal consultation? You benefit from our years of experience, our highly skilled staff and our comprehensive service catalog. Please contact us.

Contact form

WITTENSTEIN Ltd. - 3 The Glades. Festival Way

WITTENSTEIN Ltd.

3 The Glades. Festival Way

Stoke on Trent. Staffordshire. ST1 5SQ

  • Your benefits
  • Technical data
  • Options



FeaturesLP+ Generation 3
MF-version
LPB+ Generation 3
MF-version
Power density++++

Positioning accuracy

+++
High input speed++++
Torsional rigidity+++
Space-saving design+++++





  LP+ Generation 3
MF-version
LPB+ Generation 3
MF-version
Ratioi3 - 1003 - 100

Max. torsional backlash

jt [arcmin]Standard ≤ 8Standard ≤ 8
Max. acceleration torque
(max. 1000 cycles per hour)
T2B [Nm]13 - 50037 - 305
Max. input speedn1Max [rpm]80006000





 LP+ Generation 3
MF-version
LP+ Generation 3
MF-version
Output type
Smooth output shaft
Keywayed output shaft
Output flange
input type
Motor mounted version
Design
Food grade lubrication a) b)
Accessories
Couplings
Rack
Pinion
Belt pulley
B5-flange

a) Power reduction: Technical data available upon request
b) Please contact WITTENSTEIN alpha
